Jobe Valves: Vortex Partfill Valve 50mm

For Rain Water Harvesting Tanks

Vortex Partfill Valve Description

Vortex Part Fill Valve is a high flow valve for use in rain water harvesting water tanks. The float valve is designed to automatically maintain a low water level in the tank when there are extended periods of no or little rainfall.

This prevents services that use the tank from having any interruptions while also maintaining some capacity in the tank which should be able to refill due to any upcoming rain.

Applications Of Vortex Partfill Valve

This Vortex PArtfill Valve is primarily used in maintaining water levels in the following

Vortex Partfill Valve: Features & Operation Principle

Principle Of Operation

The Valve is installed through the side wall of a storage tank. It should be mounted above the overflow level of the tank to prevent backflow.
As the tank empties the weighted float travels down the cord and sits on the bottom stop to activate the valve
The valve will run until the weighted float lifts clear of the bottom stop
The float will then rise as rainwater fills the tank and falls as the tank water is used
The Valve will only function at times when rain fall is insufficient to maintain a water level in the tank above the bottom sto

Features

Compact in size
Ideal for use with all makes and models of rain water harvesting tanks
Constructed from non corroding materials
Valve can be locked in off position using the lock off switch
Up to 150mm differential obtainable (dependant on pressure)
Valve unscrews from tail for easy Valve Access
